Gentoo is one of my best Linux distro as compared to Arch which used to be my daily driver for quite some time. The great thing about gentoo for me is Portage; which is the package manager. This guide will take you through the many hurdles most people encounter during Gentoo installation, especially when trying to set up encryption.

Remember you will still need to follow the install guide to setup network, adding users among others that suit your preference. Now let us get thing started!

Gentoo linux installation encrypted btrfs openrc EFI stub boot secure boot tpm

Boot from a valid Gentoo ISO, configure the network, and set up SSH if possible.

Set up your UEFI Standard partition layout

cfdisk /dev/nvme0n1

Device          Start       End         Sectors    Size   Type
/dev/nvme0n1p1  882423808   884520959   2097152    1G     EFI System
/dev/nvme0n1p2  34816       629198847   629164032  300G   Linux filesystem

Encrypt your block device for root filesystem{#2}

cryptsetup luksFormat --type luks2 --cipher aes-xts-plain64 --key-size 512 --pbkdf argon2id --pbkdf-memory 1048576 --iter-time 4000 --label "GentooLuks" /dev/nvme0n1p2

cryptsetup open /dev/nvme0n1p2 root

Create filesystems{#3}

mkfs.vfat -n GentooBoot -F 32 /dev/nvme0n1p1
mkfs.btrfs -L GentooRoot /dev/mapper/root

Setup Mounts

mkdir -p /mnt/gentoo
mount LABEL=GentooRoot /mnt/gentoo/

# Create btrfs subvolumes accordingly your needs
btrfs su cr /mnt/gentoo/{@,@home,@.snapshots,@usr,@opt,@srv,@db,@log,@tmp,@crash,@spool,@portage,@NetworkManager,@binpkgs,@distfiles,@boot}

umount -l /mnt/gentoo

mount -o subvol=@ LABEL=GentooRoot /mnt/gentoo

mkdir -p /mnt/gentoo/{home,.snapshots,usr,opt,srv,boot,efi,var/{db,log,tmp,crash,spool,lib/{portage,NetworkManager},cache/{binpkgs,distfiles}}}

mount -o subvol=@home LABEL=GentooRoot /mnt/gentoo/home
mount -o [email protected] LABEL=GentooRoot /mnt/gentoo/.snapshots
mount -o subvol=@usr LABEL=GentooRoot /mnt/gentoo/usr
mount -o subvol=@opt LABEL=GentooRoot /mnt/gentoo/opt
mount -o subvol=@srv LABEL=GentooRoot /mnt/gentoo/srv
mount -o subvol=@db LABEL=GentooRoot /mnt/gentoo/var/db
mount -o subvol=@log LABEL=GentooRoot /mnt/gentoo/var/log
mount -o subvol=@tmp LABEL=GentooRoot /mnt/gentoo/var/tmp
mount -o subvol=@crash LABEL=GentooRoot /mnt/gentoo/var/crash
mount -o subvol=@spool LABEL=GentooRoot /mnt/gentoo/var/spool
mount -o subvol=@portage LABEL=GentooRoot /mnt/gentoo/var/lib/portage
mount -o subvol=@NetworkManager LABEL=GentooRoot /mnt/gentoo/var/lib/NetworkManager
mount -o subvol=@binpkgs LABEL=GentooRoot /mnt/gentoo/var/cache/binpkgs
mount -o subvol=@distfiles LABEL=GentooRoot /mnt/gentoo/var/cache/distfiles
mount -o subvol=@boot LABEL=GentooRoot /mnt/gentoo/boot
mount LABEL=GentooBoot /mnt/gentoo/efi

Download your preferred openrc stage3 file and verify its integrity{#4}

Some LLVM/musl Stages may not work

cd /mnt/gentoo
wget stage3-amd64-hardened-openrc-xxxx.tar.xz
wget stage3-amd64-hardened-openrc-xxxx.tar.xz.asc

gpg --import /usr/share/openpgp-keys/gentoo-release.asc
gpg --verify stage3-amd64-<release>-<init>.tar.xz.asc

# Once verified, extract it
tar xpvf stage3-*.tar.xz --xattrs-include='*.*' --numeric-owner -C /mnt/gentoo

Configuring portage

nano /mnt/gentoo/etc/portage/make.conf

COMMON_FLAGS="-march=native -O2 -pipe"
ACCEPT_LICENSE="*"
FEATURES="${FEATURES} getbinpkg"
FEATURES="${FEATURES} binpkg-request-signature"

Copy DNS info

cp --dereference /etc/resolv.conf /mnt/gentoo/etc/

Preparing for the chroot

mount --types proc /proc /mnt/gentoo/proc
mount --rbind /sys /mnt/gentoo/sys
mount --make-rslave /mnt/gentoo/sys
mount --rbind /dev /mnt/gentoo/dev
mount --make-rslave /mnt/gentoo/dev
mount --bind /run /mnt/gentoo/run
mount --make-slave /mnt/gentoo/run

chroot /mnt/gentoo /bin/bash
source /etc/profile

export PS1="(chroot) ${PS1}"

Configure the system

# Fetch the latest snapshots
emerge-webrsync

# Setting up for binary packages
getuto

# Pick the nearest mirrors
emerge --ask --verbose --oneshot app-portage/mirrorselect
mirrorselect -i -o >> /etc/portage/make.conf

# Update the Gentoo ebuild repository
emerge --sync

# Choose your preferred openrc profile (Some LLVM/musl profiles may not work)
eselect profile list
[21] default/linux/amd64/23.0/hardened (stable) *

eselect profile set 21

# Enable cpu specific optimizations
emerge --ask --oneshot app-portage/cpuid2cpuflags
cpuid2cpuflags
echo "*/* $(cpuid2cpuflags)" > /etc/portage/package.use/00cpu-flags

# Update the @world set
emerge -avuDUg @world

# Review & remove obsolete packages
emerge --ask --pretend --depclean
emerge --ask --depclean

# Install your preferred text editor
emerge --ask app-editors/nano

Set up localizations

nano /etc/locale.gen

en_US.UTF-8 UTF-8

locale-gen

eselect locale list
[4]  en_US.utf8 *
eselect locale set 4

ln -sf /usr/share/zoneinfo/YourRegion/City /etc/localtime

env-update && source /etc/profile && export PS1="(chroot) ${PS1}"

Configure installkernel for initramfs

echo "sys-kernel/installkernel dracut" >> /etc/portage/package.use/installkernel

Install some required packages

emerge --ask sys-kernel/linux-firmware sys-firmware/sof-firmware sys-fs/btrfs-progs sys-fs/cryptsetup sys-kernel/installkernel

Configure dracut

nano /etc/dracut.conf

hostonly="yes"
hostonly_mode=strict
add_dracutmodules+=" crypt "

Installing a distribution kernel

emerge --ask sys-kernel/gentoo-kernel-bin

echo 'USE="dist-kernel"' >> /etc/portage/make.conf

Add fsbab mounts

nano /etc/fstab

LABEL=GentooRoot / btrfs rw,nodev,noatime,lazytime,skip_balance,nodatacow,ssd,discard,space_cache=v2,commit=120,subvol=/@ 0 0
LABEL=GentooRoot /home btrfs rw,nodev,noatime,lazytime,skip_balance,nodatacow,ssd,discard,space_cache=v2,commit=120,subvol=/@home 0 0
LABEL=GentooRoot /.snapshots btrfs rw,nodev,noatime,lazytime,skip_balance,nodatacow,ssd,discard,space_cache=v2,commit=120,subvol=/@.snapshots	0 0
LABEL=GentooRoot /usr btrfs rw,nodev,noatime,lazytime,skip_balance,nodatacow,ssd,discard,space_cache=v2,commit=120,subvol=/@usr	0 0
LABEL=GentooRoot /opt btrfs rw,nodev,noatime,lazytime,skip_balance,nodatacow,ssd,discard,space_cache=v2,commit=120,subvol=/@opt 0 0
LABEL=GentooRoot /srv btrfs rw,nodev,noatime,lazytime,skip_balance,nodatacow,ssd,discard,space_cache=v2,commit=120,subvol=/@srv 0 0
LABEL=GentooRoot /var/db btrfs rw,nosuid,nodev,noexec,noatime,lazytime,skip_balance,ssd,discard,space_cache=v2,compress-force=zstd:10,commit=120,subvol=/@db	0 0
LABEL=GentooRoot /var/log btrfs rw,nosuid,nodev,noexec,noatime,lazytime,skip_balance,nodatacow,ssd,discard,space_cache=v2,commit=120,subvol=/@log	0 0
LABEL=GentooRoot /var/tmp btrfs rw,nosuid,nodev,noatime,lazytime,skip_balance,nodatacow,ssd,discard,space_cache=v2,commit=120,subvol=/@tmp	0 0
LABEL=GentooRoot /var/crash btrfs rw,nosuid,nodev,noexec,noatime,lazytime,skip_balance,nodatacow,ssd,discard,space_cache=v2,commit=120,subvol=/@crash	0 0
LABEL=GentooRoot /var/spool btrfs rw,nodev,noatime,lazytime,skip_balance,nodatacow,ssd,discard,space_cache=v2,commit=120,subvol=/@spool 0 0
LABEL=GentooRoot /var/lib/portage btrfs rw,nodev,noatime,lazytime,skip_balance,nodatacow,ssd,discard,space_cache=v2,commit=120,subvol=/@portage 0 0
LABEL=GentooRoot /var/lib/NetworkManager btrfs rw,nodev,noatime,lazytime,skip_balance,nodatacow,ssd,discard,space_cache=v2,commit=120,subvol=/@NetworkManager 0 0
LABEL=GentooRoot /var/cache/binpkgs btrfs rw,nosuid,nodev,noexec,noatime,lazytime,skip_balance,ssd,discard,space_cache=v2,compress-force=zstd:10,commit=120,subvol=/@binpkgs 0 0
LABEL=GentooRoot /var/cache/distfiles btrfs rw,nosuid,nodev,noexec,noatime,lazytime,skip_balance,ssd,discard,space_cache=v2,compress-force=zstd:10,commit=120,subvol=/@distfiles 0 0
LABEL=GentooRoot /boot btrfs rw,nosuid,nodev,noexec,noatime,lazytime,skip_balance,nodatacow,ssd,discard,space_cache=v2,commit=120,subvol=/@boot 0 0
LABEL=GentooBoot /efi vfat rw,nosuid,nodev,noexec,relatime,fmask=0077,dmask=0077,codepage=437,iocharset=ascii,shortname=mixed,utf8,discard,flush,errors=remount-ro	0 2

Installing some necessary system tools

emerge --ask --autounmask-continue app-admin/sudo app-shells/bash-completion net-misc/networkmanager

# Add sudo privileged user account
useradd -m -s /bin/bash -G audio,video username
passwd username

EDITOR=nano visudo
username ALL=(ALL) ALL

# Set the hostname
echo gentoo > /etc/hostname

Configure the clock options

nano /etc/conf.d/hwclock

clock="local"
clock_systohc="YES"

Configure OpenRC

nano /etc/rc.conf

rc_parallel="YES"
rc_autostart_user="NO"

Configure installkernel for automated efistub booting{#5}

nano /etc/portage/package.accept_keywords/installkernel

sys-kernel/installkernel
sys-boot/uefi-mkconfig
app-emulation/virt-firmware

echo "sys-kernel/installkernel efistub" >> /etc/portage/package.use/installkernel

# And Rebuild the installkernel
emerge sys-kernel/installkernel

mkdir -p /efi/EFI/Gentoo

# Generate initramfs again using installkernel
installkernel -a /lib/modules

Configure kernel parameters

nano /etc/default/uefi-mkconfig

KERNEL_CONFIG="%entry_id %linux_name Linux %kernel_version ; rd.luks.label=GentooLuks root=LABEL=GentooRoot rootfstype=btrfs rootflags=subvol=@ video=efifb:mode=0"

Finalize and reboot

# Create a boot entry
uefi-mkconfig

# If your EFI stub boot isn't working, consider using other boot methods
reboot

Configure Secure Boot{#6}

emerge --ask app-crypt/efitools app-crypt/sbsigntools dev-libs/openssl

Key generation

# Disable secureboot if you haven’t already
dmesg | grep -i "secure"  # Checking Secure Boot Status

mkdir -p /etc/efikeys && cd /etc/efikeys

# Saving the current keys
efi-readvar -v PK -o old_PK.esl
efi-readvar -v KEK -o old_KEK.esl
efi-readvar -v db -o old_db.esl
efi-readvar -v dbx -o old_dbx.esl

# Creating a GUID
uuidgen --random > guid.txt

# Creating new keypairs
openssl req -new -x509 -newkey rsa:4096 -subj "/CN=My Platform Key/" -keyout pk.key -out pk.crt -days 3650 -nodes -sha512
openssl req -new -x509 -newkey rsa:4096 -subj "/CN=My Key Exchange Key/" -keyout kek.key -out kek.crt -days 3650 -nodes -sha512
openssl req -new -x509 -newkey rsa:4096 -subj "/CN=My Signature DB Key/" -keyout db.key -out db.crt -days 3650 -nodes -sha512

# Creating signature lists and sign with the created keys
cert-to-efi-sig-list -g "$(< guid.txt)" pk.crt pk.esl
sign-efi-sig-list -k pk.key -c pk.crt PK pk.esl pk.auth

cert-to-efi-sig-list -g "$(< guid.txt)" kek.crt kek.esl
cert-to-efi-sig-list -g "$(< guid.txt)" db.crt db.esl

# Now combining them with the older keys
cat old_KEK.esl kek.esl > combined_KEK.esl
cat old_db.esl db.esl > combined_db.esl

Enrolling the keys

Reset Secure Boot to setup mode & update the Secure Boot database

efi-updatevar -e -f old_dbx.esl dbx
efi-updatevar -e -f combined_db.esl db
efi-updatevar -e -f combined_KEK.esl KEK
efi-updatevar -f pk.auth PK

Enabling Secure Boot

# Remove all unsigned EFI binaries from ESP
rm /efi/EFI/Gentoo/*

# Now sign the module
sbsign --key /etc/efikeys/db.key \
       --cert /etc/efikeys/db.crt \
       --output "/lib/modules/$(uname -r)/vmlinuz" \
       "/lib/modules/$(uname -r)/vmlinuz"

# And generate the module
installkernel

# Verify the EFI Binary & Enable the Secure Boot
sbverify --cert /etc/efikeys/db.crt /efi/EFI/Gentoo/vmlinuz-$(uname -r).efi

Encryption setup with using Clevis

Add the guru repository to install clevis

emerge --ask app-eselect/eselect-repository
eselect repository enable guru && emerge --sync

ACCEPT_KEYWORDS="~amd64" emerge -a app-crypt/clevis

Secure Boot key encryption{#7}

Encrypt the Signature DB and bind it to the TPM PCR

clevis encrypt tpm2 '{"pcr_bank":"sha256","pcr_ids":"0"}' < /etc/efikeys/db.key > /etc/efikeys/db.key.jwe

Now you can store your important keys on the safe place

Automated module signing with an emerge phase hook

Ensure TPM is functioning correctly and the db.crt and db.key.jwe files are accessible from their specified paths, then sbsign should sign the module during the kernel installation

mkdir -p /etc/portage/env/sys-kernel

nano /etc/portage/env/sys-kernel/gentoo-kernel-bin

pre_pkg_postinst() {
sbsign --key <(clevis decrypt < /etc/efikeys/db.key.jwe) \
       --cert /etc/efikeys/db.crt \
       --output "/lib/modules/$(uname -r)/vmlinuz" \
       "/lib/modules/$(uname -r)/vmlinuz"
}

# Script should have execute permissions
chmod +x /etc/portage/env/sys-kernel/gentoo-kernel-bin

# Now rebuild the kernel and verify the EFI binaries
emerge -1 gentoo-kernel-bin

sbverify --cert /etc/efikeys/db.crt /efi/EFI/Gentoo/vmlinuz-$(uname -r).efi
sbverify --cert /etc/efikeys/db.crt /efi/EFI/Gentoo/vmlinuz-$(uname -r)-old.efi

Auto Luks2 unlocking

Check out the Gentoo wiki before proceeding, it may have bugs

clevis luks bind -d /dev/nvme0n1p2 tpm2 '{"pcr_bank":"sha256","pcr_ids":"0,7,9"}'

# Then regenerate the initramfs
installkernel

If you experience any issues during installation, please follow the official Gentoo Linux Installation guide. I used references from Gentoo Wiki and ArchWiki with some minor tweaks myself. I hope you find something helpful.

That should be it! Reboot your system and enjoy Gentoo Linux..
